Rail Mounted Container Gantry RMG Crane
Rail-Mounted Container Gantry Crane for Efficient Port Operations
Heavy-Duty Rail-Mounted Gantry Crane for Container Handling
Container Gantry Crane on Rails for Seamless Logistics
Rail-Mounted Gantry (RMG) Crane for Port and Intermodal Yards
High-Capacity Rail-Mounted Container Crane for Industrial Use
Automated Rail-Mounted Gantry Crane for Stacking Containers
Durable Rail-Mounted Gantry Crane for Heavy Load Transport
Rail-Mounted Container Gantry Crane for Efficient Port Operations
Heavy-Duty Rail-Mounted Gantry Crane for Container Handling
Container Gantry Crane on Rails for Seamless Logistics
Rail-Mounted Gantry (RMG) Crane for Port and Intermodal Yards
High-Capacity Rail-Mounted Container Crane for Industrial Use
Automated Rail-Mounted Gantry Crane for Stacking Containers
Durable Rail-Mounted Gantry Crane for Heavy Load Transport
Authentication mark:
ccc
ce
ABS
BV
CCS
For customized products, please fill out information and submit the form.
Capacity:
Lifting Height:
Span:
Voltage/Hertz:
Working Class:
  • A3
  • A5
  • A8
Sling available:
  • available_img available_img_active Lifting hook
  • available_img available_img_active Grab bucket
Apply : A Rail Mounted Gantry (RMG) is a specialized material handling equipment used in ports , container terminals, and intermodal yards for efficient cargo movement .
SUBMIT
CONSULT
CATALOGUE
PRODUCT OVERVIEW



Rail-Mounted Gantry Cranes (RMG Crane)
RMG crane are electric cranes that move on rails. They are mainly used in ports and container yards. Compared to diesel cranes, they are more efficient, better for the environment, and cost less to operate.

These cranes can stack containers higher and handle them more precisely. Because they run on tracks, they work in a fixed area but are easier to automate. They make better use of yard space and can work at night with remote control.

A newer type called Nested RMG (Double-Rail RMG) lets two cranes work in the same area, making operations more flexible.


5G & RTK Technology in RMG Cranes
Modern RMG cranes use 5G and RTK for precise operation:

  • RTK gives accuracy within 1-3 cm

  • 5G allows instant data transfer for smooth movement


Key Applications:

  • Accurate Container Handling: Lifts containers correctly without mistakes

  • Automated Path Planning: Finds the fastest way to move containers

  • Collision Avoidance: Detects and avoids obstacles


Full Automation Examples:

  • Remote-controlled cranes (±2 cm accuracy via 5G)

  • Driverless vehicles using RTK

  • Smart systems that improve efficiency by 40%


Main Benefits:

  • Strong lifting: Handles 20' and 40' containers (with twin-lift option)

  • Electric power: No pollution, lower costs

  • Fast operation: Moves quickly even with heavy loads

  • Precise control: Special drives reduce swinging

  • Durable: Steel wheels and strong structure last long


Our RMG Crane Features:

  • Advanced controls (Siemens PLC/Schneider systems)

  • Remote monitoring (RCMS)

  • Custom lifting options (single/double drum)

  • High-precision spreaders

  • Circular trolley for better balance

  • Anti-sway system for safety

  • Comfortable cabin with good visibility


Special Chinese Market Models:
Our double-beam RMG cranes have:

  • 40.5-ton capacity

  • 45m span

  • 18.9m lifting height

  • "Stack 5, pass 6" capability (can stack 4 high with top space for moving)

  • Special features for fertilizer container handling:

    • Video monitoring

    • Smart lightning protection

    • Anti-lift system

    • 8-rope anti-sway

    • Automatic trolley locking


The New Smart Cabin Design
Our latest RMG features:

  • Better visibility for intermodal operations

  • Modular design for faster delivery

  • Future-ready for automation upgrades

  • Dynamic Load Control (ALC) system allows most operations by moving just the spreader (not the whole crane)


Why Choose Us?
✔ Custom designs for your yard
✔ Energy efficient operation
✔ Meets all global safety standards
✔ Faster container handling
✔ Less maintenance needed
✔ Longer equipment life

APPLICATION SCENARIO



RMGs in New & Automated Terminals

New and automated container terminals often use RMGs because they:

  • Work better than other cranes

  • Are easy to operate and maintain

  • Can be automated

  • Move containers fast at low cost

  • Use yard space well

In fully automated terminals, RMGs work in closed yards without moving to other areas.


Example: A Large RMG

One RMG set a record for handling extra-wide cargo:

  • Size: 67.5m long, 27.7m wide, 26.4m high

  • Weight: 430 tons

  • Cargo Size: 49,300 cubic meters

  • Challenge: Cargo stuck out 20m from each side of the ship


Where RMGs Are Used

Container Port Yards

RMGs are key in automated terminals:

  • Stack, load, and move containers

  • High reach allows "stack 4, pass 5" layouts

  • Example: Xiamen Port uses automated RMGs for faster work


Rail Hubs

RMGs connect rail and port transport easily.


Cross-Border Logistics Parks

They handle import/export containers and can work automatically with smart controls.


Smart Ports

With 5G and RTK, RMGs:

  • Position containers within centimeters

  • Plan paths automatically

  • Example: Tangshan Port and Longgong Port use 5G+RTK for better efficiency


Key Benefits

  • Saves Space – Stacks containers high

  • Eco-Friendly – Electric power cuts pollution

  • Easy Automation – Works with smart systems



Rail-Mounted Gantry Cranes (RMGs) - Key Applications

RMGs are strong lifting systems for cargo handling in ports, yards, and industrial areas. They work in these main areas:

1. Ports & Container Terminals

  • Ship Loading/Unloading: RMGs move containers between ships and storage areas fast.

  • Yard Stacking: They stack containers high (6+ rows) to save space.

  • Intermodal Transfer: RMGs move containers between trucks, trains, and storage easily.


2. Intermodal Yards & Logistics Hubs

  • Rail-to-Truck Transfer: RMGs move containers from trains to trucks (or back) with precision.

  • Depot Storage: They organize containers in large yards for quick access.


3. Industrial & Bulk Material Handling

  • Heavy Cargo: RMGs lift steel coils, pallets, and machines with special attachments.

  • Bulk Materials: Some RMGs handle scrap metal, coal, or grain in industrial yards.


4. Automated & Smart Terminals

  • Automated Handling: RMGs work with driverless vehicles (AGVs) for unmanned operations.

  • Remote Control: Operators control RMGs from safe cabins or control centers.


5. Inland Container Depots (ICD) & Freight Stations

  • Temporary Storage: RMGs stack containers before customs checks or final transport.

  • Cross-Docking: They quickly move containers between rail and road to save time.


Why RMGs Work Best

  • Electric/Diesel Options: Electric RMGs for ports, diesel for remote yards.

  • Fast & Precise: Quick movement with heavy loads reduces waiting time.

  • Flexible Attachments: Use spreaders (20’/40’/twin-lift), grabs, or hooks for different cargo.

  • Space Saving: Rail movement allows tighter spaces than rubber-tired cranes (RTGs).
